High Performance Train Signal Strong Commonality CRH380BL Sign Train Marker Light

Share
Train marker lights are essential safety and identification devices in railway transportation. They are primarily used at the front, rear, and sides of trains to indicate the train's position, direction, and operational status. Marker lights not only provide visual signals in low-visibility conditions such as at night or in bad weather but also ensure the safe operation of trains in emergency situations.


  • Description
  • Specification
  • Drawings

Product Features
1. High Brightness and Energy Efficiency:Utilizing high-brightness LED light sources to ensure good visibility in nighttime or adverse weather conditions.Low power consumption design, extending service life and reducing energy consumption.
2. Durability and Protection:Protection ratings typically reach IP67 or higher, providing resistance to dust, moisture, and external impacts.Capable of withstanding extreme temperatures ranging from -40°C to +70°C.
3. Smart Control and Automation:Supports various control methods, including manual, automatic, and remote control.Can be integrated with the train's control system to achieve automatic switching and status monitoring.
4. Lightweight and Compact Design:Made from lightweight materials to reduce the burden on the train.
Compact structural design for easy installation and maintenance.

Product Name
Auxiliary Headlamp
Train Marker Light
 Headlamp
Model
CRH380BL
CRH380BL
CRH3F
IP Grade
IP68
IP67
IP67
Dimensions
270*206*316
206*80
253*200
Rated Voltage
DC24V
DC24V
110V
KW
20W
12W
35W
Ambient Temperature
-35℃~40℃
-35℃~40℃
-35℃~40℃
Color Temperature
4500K±500K
4500K±500K
4500K±500K
Illuminance
65000cd
25cd
600000cd
Fire Protection Standard
EN45545-2:2013
EN45545-2:2013
EN45545-2:2013
