Railway UIC Standard Air brake Hose

Share

The utility model is used as a flexible connecting pipe in the air braking system of freight cars, and is connected with the air braking system of rail cars and locomotives. Brake pipe pnuematic half coupling for rail with UIC and AAR certificate is applied in the railway air brake system.

  • Description
  • Specification

The utility model is used as a flexible connecting pipe in the air braking system of freight cars, and is connected with the air braking system of rail cars and locomotives. Brake pipe pnuematic half coupling for rail with UIC and AAR certificate is applied in the railway air brake system.

Delivery medium: compressed air (oil resistance)

Temperature available: -50℃ to 70 ℃

Min.Burst Pressure:7 Mpa

Available reference standards: UIC830-1/0, BS3682-94 part1, AAR M601&AAR M601

Tube: black, smooth, synthetic rubber.

Reinforcement: high strength synthetic cord.

Cover: black, smooth (wrapped finish), long lasting rubber, weathering, ozone, and oil resistant.

Railway UIC Standard Air brake Hose

Inside diameter (mm)

Outside diameter (mm)

Burst pressure(bar)

18

32

70

22

37

70

28

46

70

35

51

70
