It is used in railway, locomotive vehicle electric control system.
The connection type is directly bayonet connection.
Contact element struction: Springtac TM type.
The contact type between contact element and wire end : Cool pressure connection terminal
Suitable standard: GB/T25022-2010.
environment temperature:-50℃~70℃.
relative humidity:90±3%(when temperature is 25℃)
altitude:≤2500m
related current:15A
related voltage:AC 250v
insulation resistance:≥500MΩ
contact resistance:≤2mΩ
withstand voltage:≥2000v 50Hz AC
level of protection: IP65
mechanical life:≥1500
wire: 5*4mm2
