It is used in railway electric control system.
The connection type is push-pull type fast connection.
Contact element struction: Cone contact type.
The contact type between contact element and wire end : Cool pressure connection terminal contact back nut to fix.
Suitable standard: GB/T25023-2010.
environment temperature:-50℃~70℃.
relative humidity:90±3%(when temperature is 25℃)
altitude:≤2500m
related current:425A
related voltage:AC 500v
insulation resistance:≥500MΩ
contact resistance:≤0.2mΩ
withstand voltage:≥2500v 50Hz AC
level of protection: IP65
mechanical life:≥1500
wire: 150mm2 or 120mm2
Connector with anti-theft
