Train Locomotive Forced Ventilation ZQDR250A23 Railway Traction Motor

Share

Main Features

1.Completely interchangeable with GE761A23 traction motor;
2.Imported SKF or FAG bearing is used,
3.The motor can be operated normally under the condition that the altitude is not more than 1200m, and with ambient temperature within -25'c to 40°c;


  • Description
  • Specification
  • Drawings

Product Name
ZQDR250A23 Railway Traction Motor
Rated Voltage
346V
Rated Current
670A
Rated Speed
512r/min
Max Voltage
1075V
Max Current
900A
Max Speed
3100r/min
Exciting
series
Insulation class
H
Cooling Mode
Forced ventilation
Cooling Air Volume
57m3/min
